Pressure Regulator PRV-100
The PRV-100 automatically maintains preset pressure regardless of inlet fluctuations. Essential for protecting sensitive irrigation components and ensuring uniform water distribution.
Certified materials — ISO-grade PVC compound
Custom runs available — tell us diameter, length, color
Bulk shipping — freight handled in-house
Pressure Regulator PRV-100 - Automatic Pressure Control
The PRV-100 Pressure Regulator is a critical component for any professional irrigation system. This automatic valve maintains consistent downstream pressure regardless of inlet variations.
Key Features:
- Automatic Regulation: Maintains preset pressure without adjustment
- Spring-Loaded Design: Responds instantly to pressure changes
- High Flow Capacity: Minimal pressure loss at full flow
- Easy Adjustment: External adjustment screw for pressure setting
- Durable Construction: UV-resistant polymer body
Technical Specifications:
- Inlet/Outlet: 1" BSP threaded
- Adjustment Range: 0.5 - 6.0 bar
- Maximum Flow: 10 m³/h
- Accuracy: ±0.2 bar
- Material: Glass-filled nylon with EPDM seals
Applications:
- Drip irrigation pressure control
- Micro-sprinkler system protection
- Zone pressure management
- Water hammer prevention
